    Modular flue gas probe 700 mm, Ø 8 mm, Tmax 1000 °C

    0600 8765
    $1 797.00 $1 976.70
    1
  1. Easy probe shaft replacement via quick-change click system
  2. NO2/SO2 special hose (length: 2.2 m)
  3. Flue gas path and temperature channel can be connected to the instrument via a bayonet lock
  4. Integrated thermocouple probe for temperature measurements up to 1000 °C
    5. The modular flue gas probe with 700 mm long probe shaft including integrated thermocouple up to 1000 °C and quick-change click system (for quick replacement of the probe shaft).
    On the modular flue gas probe with 700 mm long probe shaft, the flue gas path and temperature channel can be conveniently connected to the measuring instrument via a practical bayonet lock. The probe shaft is also easy to replace, thanks to the quick-change click system on the handle. The thermocouple NiCr-Ni, which is integrated in the probe shaft, enables temperature measurement up to 1000 °C. The probe is also supplied with a cone for attachment.

    Modular flue gas probe 700 mm including cone for attachment, thermocouple NiCr-Ni Tmax 1000 °C and NO2/SO2 special hose 2.2 m.

    General technical data

    Weight
    690 g
    Length probe shaft
    700 mm
    Product-/housing material
    Metal housing
    Cable length
    2.2 m
    Diameter probe shaft
    8 mm
    Product colour
    Black; silver
    Temperature maximum
    1,000 °C
    Connection
    Bayonet
