    Frozen food probe, corkscrew design - Frozen food probe

    0603 3292
  1. Can easily be screwed into frozen food, no pre-drilling required
  2. Cable detachable
  3. Very robust design
  4. Thermocouple type T
  5. Frozen food probe, corkscrew design, Tmax handle and cable +158°F
    The frozen goods probe (TC type T) is primarily used for measuring the core temperature of frozen food. Thanks to a special handle and its helical tip, it can be screwed directly into frozen food without the need for pre-drilling.

    1 x frozen goods probe (TC type T) for screw-in use without pre-drilling, including plug-in cable (cable length 1.7 m).

    Temperature - TC Type T (Cu-CuNi)

    Measuring range
    -58.0° to 662.0 °F / -50 to +350 °C
    Accuracy
    ±0.4 °F (-4.0° to 158.0 °F) / ±0.2 °C (-20 to +70 °C)
    Class 1 (Remaining Range) ¹⁾
    Reaction time
    8 sec
    1) According to standard EN 60584-2, the accuracy of Class 1 refers to -40 to +350 °C (Type T).

    General technical data

    Weight
    4.66 oz. / 132 g
    Dimensions
    72 in. / 1840 mm
    Length probe shaft tip
    1.181 in. / 30 mm
    Diameter probe shaft
    0.315 in. / 8 mm
    Diameter probe shaft tip
    0.157 in. / 4 mm
    Cable length
    5.577 ft. / 1.7 m
    Fixed cable
    yes
    Protection class
    IP65
    Housing
    Stainless steel / GFK
    Length probe shaft
    4.331 in. / 110 mm
    Product colour
    white; silver
