    Modular flue gas probe, 335 mm, Ø 8 mm, Tmax 1000 °C

    0600 8764
    Modular flue gas probe
    1
  1. Quick-Change Click System – Effortlessly replace the probe shaft for increased flexibility and convenience.
  2. NO2/SO2 Special Hose – Includes a 2.2 m hose designed for precise NO2 and SO2 measurement.
  3. Secure Bayonet Connection – Easily attach the flue gas path and temperature channel to the instrument.
  4. High-Temperature Capability – Integrated thermocouple enables temperature measurements up to 1000 °C.
    5. The modular flue gas probe (335 mm, Ø 8 mm) is designed for high-precision emissions measurement in demanding industrial environments. Featuring an integrated thermocouple for temperature readings up to 1000 °C, a quick-change click system for easy probe shaft replacement, and a secure bayonet lock for instrument connection, it ensures reliable performance and user convenience.
    On the modular flue gas probe with 335 mm long probe shaft, the flue gas path and temperature channel can be conveniently connected to the measuring instrument via a practical bayonet lock. The probe shaft is also easy to replace, thanks to the quick-change click system on the handle. The thermocouple NiCr-Ni, which is integrated in the probe shaft, enables temperature measurement up to 1000 °C. The probe is also supplied with a cone for attachment.

    Modular flue gas probe 335 mm including cone for attachment, thermocouple NiCr-Ni (TI) Tmax 1000 °C and NO2/SO2 special hose 2.2 m.

    General technical data

    Weight
    606 g
    Length probe shaft
    335 mm
    Product-/housing material
    Metal housing
    Cable length
    2.2 m
    Diameter probe shaft
    8 mm
    Product colour
    Black; silver
    Temperature maximum
    1,000 °C
    Connection
    Bayonet
