- Home
- testo 400 IAQ and comfort kit with tripod
testo 400 IAQ and comfort kit with tripod
Product no. 0563 0401
£ 3,569.00with VAT £ 4,282.80
1
Delivery time: 3 – 5 working days
testo 400 IAQ and comfort kit with tripod
Product no. 0563 0401Your benefits
A measuring instrument for all climate-related parameters
Standard-compliant determination of the comfort level: PMV and PPD as well as draught and turbulence as per EN ISO 7730 and ASHRAE 55
In the kit: testo 400 universal IAQ instrument, CO2 probe (with Bluetooth® handle), turbulence probe with cable, globe thermometer (Ø 150 mm) with cable, measuring tripod with bag, case
Extendible with a wide range of probes
Analytical software for creating professional reports and measurement data management
Digital probes eliminate any additional measurement uncertainty of the measuring instrument
Ideal kit for IAQ professionals, with a focus on indoor air quality and comfort level. You will receive the testo 400 universal IAQ measuring instrument with intuitive measurement menus, one CO₂ probe (with Bluetooth® handle), one turbulence probe and one globe thermometer Ø 150 mm (both with fixed cable). Use the measuring tripod to ensure standard-compliant positioning of the probes. In combination with the IAQ data logger, which is available to order separately, long-term measurements up to 2 weeks can be recorded, even without the IAQ measuring instrument.
A measuring instrument for all climate-related parameters
Product registration
When you register your product, we will extend the regular manufacturer's warranty by one year.
Description
Delivery Scope
- testo 400 universal IAQ instrument, silicone hoses, mains unit with USB cable, calibration protocol, instruction manual (0560 0400)
- CO2 probe with Bluetooth® including temperature and humidity sensor (consisting of CO2 probe head and Bluetooth® handle), 4 x AA batteries, table stand and calibration protocol (0632 1551) Please do not use the probe in condensing atmospheres. For continuous application in high-humidity ranges
> 80% RH at ≤ 30 °C for > 12 h
> 60% RH at > 30 °C for > 12 h
Please get in touch with Testo Service or contact us via the Testo website - Turbulence probe with fixed cable and calibration protocol (0628 0152)
- Globe thermometer (Ø 150 mm, TC type K) with fixed cable (0602 0743)
- Measuring tripod for comfort level measurements, consisting of a folding stand, mounting rod, handheld instrument holder, 4 x probe mounts, including bag (0554 1591)
- Transport case for IAQ and comfort level measurements (0516 2400)
Details on kit components
Details on kit components
testo 400 – universal IAQ instrument
Product no.: 0560 0400
Details on kit components
CO₂ probe (digital) with Bluetooth® including temperature and humidity sensor: for measuring the indoor air quality in offices, production areas or storage facilities – measuring range 0 to 10,000 ppm, -10 to +50 °C, 5 to 95% RH
Product no.: 0632 1551
Details on kit components
Turbulence probe (digital), wired: for determining the degree of turbulence and draught risk according to EN ISO 7730 / ASHRAE 55 – measuring range 0 to +5 m/s, 0 to +50 °C
Product no.: 0628 0152
Technical data
Temperature - NTC
| Measuring range | -40 to +150 °C |
|---|---|
| Accuracy | ±0.5 % of mv ±1 Digit (Remaining Range) ±0.4 °C ±1 Digit (+75 to +99.9 °C) ±0.2 °C ±1 Digit (-25 to +74.9 °C) ±0.4 °C ±1 Digit (-40 to -25.1 °C) |
| Resolution | 0.1 °C |
Temperature - TC Type K (NiCr-Ni)
| Measuring range | -200 to +1370 °C |
|---|---|
| Accuracy | ±(0.3 °C + 0.1 % of mv) ±1 Digit |
| Resolution | 0.1 °C |
Differential pressure (internal sensor) - Piezoresistive
| Measuring range | 0 to +200 hPa |
|---|---|
| Accuracy | ±(0.1 hPa + 1.5 % of mv) ±1 Digit (25.001 to 200 hPa) ±(0.3 Pa + 1 % of mv) ±1 Digit (0 to 25 hPa) |
| Resolution | 0.001 hPa |
Absolute Pressure (internal sensor and external probe)
| Measuring range | 700 to 1100 hPa |
|---|---|
| Accuracy | ±3 hPa |
| Resolution | 0.1 hPa |
General technical data
| Weight | 510 g (instrument) |
|---|---|
| Dimensions | 210 x 95 x 39 mm ((LxWxH)) |
| Operating temperature | -5 to +45 °C |
| Product-/housing material | Plastic |
| Protection class | IP40 |
| Connectable probes | 4 x digital Bluetooth® probe or testo Smart Probe; 2 x digital probe with fixed cable or temperature probe NTC with fixed cable (via Testo Universal Connector - TUC); 2 x temperature probe TC type K with fixed cable |
| Product colour | black/orange |
| Camera image size | Main camera: 8.0 MP; Front camera: 5.0 MP |
| Battery life | approx. 10 hrs continuous operation |
| Display type | 5.0" touch display, HD 1280*720 pixels, IPS (160 k) |
| Power supply | Rechargeable li-ion battery (5550 mAh) |
| Interface | Bluetooth®; USB; WLAN |
| Memory | 2 GB; 1,000,000 measuring values |
| Storage temperature | -20 to +60 °C |
| *TUC connection (Testo Universal Connector): For the connection of fixed cable digital probes and NTC probes. | |
Temperature - NTC
| Measuring range | 0 to +50 °C |
|---|---|
| Accuracy | ±0.5 °C |
| Resolution | 0.1 °C |
Humidity - Capacitive
| Measuring range | 5 to 95 %RH |
|---|---|
| Accuracy | Hysteresis: ±1.0 %RH ±0.06 %RH/K (0 to +50 °C) long-term stability: ±1 %RH / year ±3 %RH (10 to 35 %RH) ±3 %RH (65 to 90 %RH) ±5 %RH (Remaining Range) ±2 %RH (35 to 65 %RH) |
| Resolution | 0.1 %RH |
Absolute Pressure
| Measuring range | +700 to +1100 hPa |
|---|---|
| Accuracy | ±3.0 hPa |
| Resolution | 0.1 hPa |
Ambient CO₂
| Measuring range | 0 to 10000 ppm |
|---|---|
| Accuracy | ±(100 ppm + 5 % of mv) (5001 to 10000 ) ±(50 ppm + 3 % of mv) (0 to 5000 ) |
| Resolution | 1 ppm |
General technical data
| Storage temperature | -20 to +60 °C |
|---|---|
| Weight | 195 g |
| Dimensions | 295 x 50 x 40 mm |
| Operating temperature | -5 to +50 °C |
| Length probe shaft | 130 mm |
| Probe head diameter | 30 mm |
| Product colour | black/orange |
| Battery life | 21,5 h |
| Battery type | 4 x type AA batteries |
| Data transfer | Bluetooth® |
| Radio range | 20 m |
General technical data
| Storage temperature | -20 to +60 °C |
|---|---|
| Weight | 250 g |
| Dimensions | 400 x 90 x 90 mm |
| Operating temperature | 0 to +50 °C |
| Cable length | 1.4 m |
| Probe head diameter | 820 mm |
| Product colour | black/orange |
| Standards | EN ISO 7730 / ASHRAE 55 |
Temperature - NTC
| Measuring range | 0 to +50 °C |
|---|---|
| Accuracy | ±0.5 °C |
| Resolution | 0.1 °C |
Absolute Pressure
| Measuring range | +700 to +1100 hPa |
|---|---|
| Accuracy | ±3.0 hPa |
| Resolution | 0.1 hPa |
Velocity - Hot wire
| Measuring range | 0 to 5 m/s |
|---|---|
| Accuracy | ±(0.03 m/s + 4 % of mv) |
| Resolution | 0.01 m/s |
Temperature - TC Type K (NiCr-Ni)
| Measuring range | 0 to +120 °C |
|---|---|
| Accuracy | Class 1 ¹⁾ |
| 1) According to standard EN 60584-1, the accuracy of Class 1 refers to -40 to +1000 °C (Type K), Class 2 to -40 to +1200 °C (Type K), Class 3 to -200 to +40 °C (Type K). | |
General technical data
| Weight | 385 g |
|---|---|
| Dimensions | 250 x 150 x 150 mm |
| Cable length | 1.4 m |
| Emissivity | 0,95 |
| Probe head diameter | 150 mm |
| Product colour | Black |
General technical data
| Weight | 5100 g |
|---|---|
| Dimensions | 730 x 220 x 245 mm ((LxWxH)) |
| Product colour | Black |
General technical data
| Weight | 3250 g |
|---|---|
| Dimensions | 520 x 410 x 210 mm LxWxH |
| Product-/housing material | Plastic |
| Product colour | Black |
Sensor
Comfort probes
Comfort probes
Turbulence probe (digital), wired: for determining the degree of turbulence and draught risk according to EN ISO 7730 / ASHRAE 55 – measuring range 0 to +5 m/s, 0 to +50 °C
Product no.:
0628 0152
0628 0152
Comfort probes
CO₂ probe (digital) with Bluetooth® including temperature and humidity sensor: for measuring the indoor air quality in offices, production areas or storage facilities – measuring range 0 to 10,000 ppm, -10 to +50 °C, 5 to 95% RH
Product no.:
0632 1551
0632 1551
£ 525.00with VAT £ 630.00
1
Comfort probes
Lux probe (digital), wired: for measuring illuminance in workplaces (e.g. offices, production areas) – measuring range 0 to 100,000 lux
Product no.:
0635 0551
0635 0551
£ 355.00with VAT £ 426.00
1
Food probes
Food probes
Stainless steel food probe (NTC) - measuring range: -50 to +150 °C
Product no.:
0615 2211
0615 2211
£ 113.00with VAT £ 135.60
1
Food probes
Waterproof stainless steel food probe (NTC) - measuring range -50 to +150 °C
Product no.:
0615 3311
0615 3311
£ 133.00with VAT £ 159.60
1
Food probes
Robust food penetration probe (NTC) - measuring range -25 to +150 °C
Product no.:
0615 2411
0615 2411
£ 102.00with VAT £ 122.40
1
Humidity probes
Humidity probes
Humidity/temperature probe (digital) with Bluetooth®: for measurements in rooms, ventilation ducts, refrigeration systems and heat pumps – accuracy ±2% RH / ±0.5 °C, measuring range 0 to 100% RH / -20 to +70 °C
Product no.:
0636 9731
0636 9731
£ 195.00with VAT £ 234.00
1
Humidity probes
Humidity/temperature probe (digital), wired: for measurements in rooms, ventilation ducts, refrigeration systems and heat pumps – accuracy ±2% RH / ±0.5 °C, measuring range 0 to 100% RH / -20 to +70 °C
Product no.:
0636 9732
0636 9732
£ 160.00with VAT £ 192.00
1
Humidity probes
Humidity/temperature probe head: for attachment to universal Bluetooth® or cable handle – accuracy ±2% RH / ±0.5 °C, measuring range 0 to 100% RH / -20 to +70 °C
Product no.:
0636 9730
0636 9730
£ 98.00with VAT £ 117.60
1
Pitot tubes
Pitot tubes
Stainless steel Pitot tube, length 500 mm, Ø 7 mm - for measuring flow velocity
Product no.:
0635 2045
0635 2045
£ 160.00with VAT £ 192.00
1
Pitot tubes
Stainless steel Pitot tube, length 350 mm, Ø 7 mm - for measuring flow velocity
Product no.:
0635 2145
0635 2145
£ 150.00with VAT £ 180.00
1
Pitot tubes
Stainless steel Pitot tube, length 1000 mm, Ø 7 mm - for measuring flow velocity
Product no.:
0635 2345
0635 2345
£ 439.00with VAT £ 526.80
1
Pressure probes
Pressure probes
testo 510i – differential pressure measuring instrument with smartphone operation
Product no.:
0560 1510
0560 1510
£ 119.00with VAT £ 142.80
1
Pressure probes
testo 549i - High-pressure gauge operated via smartphone
Product no.:
0560 2549 02
0560 2549 02
£ 79.00with VAT £ 94.80
1
Surface probes
Surface probes
Waterproof surface temperature probe (NTC) for flat surfaces - measuring range: -50 to +150 °C
Product no.:
0615 1912
0615 1912
£ 85.00with VAT £ 102.00
1
Temperature probes
Temperature probes
testo 805i – infrared thermometer with smartphone operation
Product no.:
0560 1805
0560 1805
£ 99.00with VAT £ 118.80
1
Temperature probes
High-precision immersion/penetration probe (Pt100 temperature sensor, digital) for temperature measurements in liquids and pastes – measuring range -80 to +300 °C, accuracy up to ±0.05 °C
Product no.:
0618 0275
0618 0275
£ 478.00with VAT £ 573.60
1
Temperature probes
Immersion/penetration probe (digital) with Pt100 temperature sensor: for temperature measurements in liquids and pastes – measuring range -100 to +400 °C, accuracy up to ±0.15 °C
Product no.:
0618 0073
0618 0073
£ 243.00with VAT £ 291.60
1
Velocity
Velocity
Hot wire probe (digital) with Bluetooth® including temperature and humidity sensor: for measurements in ventilation ducts – measuring range 0 to +50 m/s, -20 to +70 °C, 5 to 95% RH
Product no.:
0635 1571
0635 1571
£ 710.00with VAT £ 852.00
1
Velocity
Hot wire probe (digital) including temperature and humidity sensor, wired: for measurements in ventilation ducts – measuring range 0 to +50 m/s, -20 to +70 °C, 5 to 95% RH
Product no.:
0635 1572
0635 1572
£ 710.00with VAT £ 852.00
1
Velocity
Vane probe (Ø 16 mm, digital) with Bluetooth® including temperature sensor: for measurements in ventilation ducts – measuring range +0.6 to +50 m/s, -10 to +70 °C
Product no.:
0635 9571
0635 9571
£ 782.00with VAT £ 938.40
1
Sets
Sets
Sets
testo 400 air flow kit with hot wire probe
Product no.:
0563 0400 71
0563 0400 71
£ 2,995.00with VAT £ 3,594.00
1
Sets
testo 400 air flow kit with 16 mm vane probe
Product no.:
0563 0400 72
0563 0400 72
£ 2,958.00with VAT £ 3,549.60
1
Sets
testo 400 IAQ and comfort kit with tripod
Product no.:
0563 0401
0563 0401
£ 3,569.00with VAT £ 4,282.80
1
Accessories
Accessories
Accessories
IAQ data logger for long-term measurements
Product no.:
0577 0400
0577 0400
£ 926.00with VAT £ 1,111.20
1
Accessories
Measuring tripod for IAQ and comfort level measurements, to ensure standard-compliant, secure positioning of measuring instrument and probes including transport bag
Product no.:
0554 1591
0554 1591
£ 429.00with VAT £ 514.80
1
Accessories
Transport case for air flow measurements
Product no.:
0516 1400
0516 1400
£ 180.00with VAT £ 216.00
1
Sensor heads
Sensor heads
16 mm vane probe head including temperature sensor; for attachment to extendable telescope for air velocity probes with universal handle – measuring range +0.6 to +50 m/s, -10 to +70 °C
Product no.:
0635 9570
0635 9570
£ 521.00with VAT £ 625.20
1
Sensor heads
High-precision 100 mm vane probe head including temperature sensor: for attachment to extendable telescope for air velocity probes with universal handle or to a universal Bluetooth® or cable handle – measuring range +0.1 to +15 m/s, -20 to +70 °C
Product no.:
0635 9370
0635 9370
£ 710.00with VAT £ 852.00
1
Sensor heads
100 mm vane probe head: for attachment to extendable telescope for air velocity probes with universal handle or to universal Bluetooth® or cable handle – measuring range +0.3 to +35 m/s, -20 to +70 °C
Product no.:
0635 9430
0635 9430
£ 329.00with VAT £ 394.80
1
Applications
IAQ measurements in the field of air conditioning and ventilation
- High-precision, location-independent and built-in differential pressure sensor, smart and intuitive measurement programs for IAQ measurements in accordance with the standards, creation of documentation on site, e-mailing of reports, versatile combination options with IAQ probes
IAQ measurements in the field of air conditioning and ventilation
Custom-combine your Testo IAQ measuring instrument with IAQ probes and accessories for your application.
With the right products, you can handle all kinds of IAQ applications:
- Air flow measurements: Flow measurements in ducts, at outlets and on filters as per EN ISO 12599 and ASHRAE 111
- Comfort level measurements: Measurement of indoor air quality or turbulence as per EN ISO 7730 and ASHRAE 55, NET measurement as per DIN 33403, PMV/PPD as per EN ISO 7730 and ASHRAE 55, WBGT measurement as per DIN 33403 and EN ISO 7243
- Measurements in laboratories and cleanrooms: Flow measurements in fume cupboards as per DIN EN 14175-3/-4, differential pressure measurements and laminar flow measurements in cleanrooms, humidity measurements in cleanrooms
Downloads
Product brochures
- Data sheet testo 400 IAQ and comfort kit with tripod(pdf, 623.1 kB)
Operating instructions
- Short instruction testo 400(pdf, 854.44 kB)
- Instruction manual testo 400(pdf, 5.24 MB)
