    testo 440 - Air velocity and IAQ measuring instrument

    Product no. 0560 4401
    testo 440 Air velocity and IAQ measuring instrument
    Volume flow measurement in ducts with the air velocity and IAQ measuring instrument testo 440
    Volume flow measurement at outlets with the air velocity and IAQ measuring instrument testo 440
    Measuring indoor air quality and comfort level using the air velocity and iaq measuring instrument testo 440
    testo 440 Air velocity and IAQ measuring instrument
    testo 440 Air velocity and IAQ measuring instrument
    testo 440 Air velocity and IAQ measuring instrument
    testo 440 Air velocity and IAQ measuring instrument
    testo 440 Air velocity and IAQ measuring instrument
    testo 440 Air velocity and IAQ measuring instrument
    This meter requires a probe for commissioning.
    Click here for sensor selection.
    Your advantages
  1. Intuitive: clearly structured measurement menus for volume flow, degree of turbulence, cooling/heating output, mould detection and long-term measurement, such as CO₂
  2. Wireless: Bluetooth® probes for extra convenience when measuring and less cable clutter in the measuring case (please order probes separately)
  3. Clear overview: large graphic display with parallel display of 3 readings
  4. Safe and reliable: internal data storage and USB port for data export
  5. Precise, reliable measurement of all air velocity and IAQ parameters with just one measuring instrument: the multifunction measuring instrument features intuitive operation with clearly structured measurement menus. Adjusting air conditioning and ventilation systems, monitoring air quality or carrying out comfort level measurements – thanks to versatile options for combining with high-quality, digital probes, you are ideally equipped to carry out your measuring task (please order probes separately).

    Description

    Use the testo 440 air velocity and IAQ measuring instrument in combination with high-quality probes to measure and store all air velocity and IAQ parameters (please order probes separately). Up to 3 probes can be connected simultaneously: a Bluetooth probe, a wired probe and a temperature probe with type K thermocouple connector. Automatic probe detection and clearly structured measurement menus guarantee simple operation and will make your day-to-day work easier.



    Measure in just a few clicks with the testo 440 multifunction measuring instrument

    Carry out your measurements quickly and easily: the air velocity and IAQ measuring instrument automatically detects each connected probe. This means that there is no need for you to manually reset the parameters when changing probes. Clearly structured measurement menus for measuring the volume flow in ducts/at outlets, funnel measurement, measuring the degree of turbulence, determining the cooling/heating output, mould detection and long-term measurement provide you with optimum support during your day-to-day work.



    Wireless and space-saving: more applications, less equipment

    Endlessly versatile: a universal handle can be connected to all probe heads – so you can master more applications using less equipment and save space.

    The Bluetooth handle makes it more convenient to carry out your measurement and guarantees less cable clutter in the case. It makes it possible to carry out measurements without any bothersome cable connection and it transfers readings up to a distance of 20 m. Or as a practical alternative, use the cable handle to connect testo probe heads. This is an advantage if Bluetooth signals are not permitted.



    Practical measurement data management

    The multifunction measuring instrument stores up to a max. 7500 measurement protocols, which can be read via a USB port and further processed as a CSV file on your computer (e.g. with Excel). With the testo BLUETOOTH/IRDA printer (please order separately), you have the option of producing a report printout of the measurement data directly on site.



    Intelligent calibration concept for maximum precision

    You can rely on accurate measurement results when using our digital probes, because the measuring instrument makes measurement uncertainty a thing of the past. You only need to send the probes in for calibration. The multifunction measuring instrument can therefore remain in continuous use.





    Advantages of measuring with the testo 440 air velocity and IAQ measuring instrument

    Precise and reliable in ducts and at air outlets

    • Large range of connectable probes: hot wire and vane probe (Ø 16 mm) for measurements in ducts; large vane probes of Ø 100 mm for measurements at air/ceiling outlets
    • Calculate volume flow quickly: in the measurement menu, simply configure the dimensions and geometry of the duct cross-section and see the volume flow displayed on the measuring instrument straight away
    • You will even find it easy to carry out measurements in particularly large ducts. This is because the extendable telescope on the hot wire and vane probe (Ø 16 mm) with universal handle can be further extended using the telescope extension – enabling you to attain a total length of 2 metres
    • Carry out measurements at air/ceiling outlets effortlessly and without using a ladder. Fit the vane probe (Ø 100 mm) with the extendable telescope with 90° angle and, if necessary, with the telescope extension (both can be ordered separately)
    • Use the vane probes in conjunction with the testovent measurement funnels and flow straighteners to test incoming / outgoing air at plate outlets, ventilation grilles and swirl outlets
    • Practical Bluetooth interface: use the air velocity probes to measure without having to deal with any bothersome cables, operate the measuring instrument by pressing the button on the handle of the probe, e.g. start or stop a timed mean calculation
    • Use the practical magnets to securely attach the multifunction measuring instrument to metal surfaces (e.g. ventilation ducts)

    Long-term monitoring of indoor air quality

    • The right probe for your requirements: probes for CO2, CO, air temperature and humidity are available as variants with Bluetooth or with fixed cable
    • Easy to use: enter the measurement period and interval in the menu for long-term measurement and track it over the course of the day
    • Internal memory for up to 7500 measurement protocols

    Turbulence measurement in accordance with EN ISO 7730 / ASHRAE 55

    • Attain a high level of accuracy, even at low air velocities, with a turbulence probe
    • Automatic calculation of draught risk and degree of turbulence in accordance with EN ISO 7730/ASHRAE 55
    • For convenient measurements at varying heights, we recommend using our measuring tripod for comfort level measurement. This makes it very easy to position turbulence probes in compliance with the standards

    Range of probes for cleanrooms and laboratories

    • Fume cupboard probe for high-precision air velocity measurement on fume cupboards
    • Thanks to the low start-up speed of 0.1 m/s, the high-precision vane probe (Ø 100 mm) is ideal for laminar flow measurements in cleanrooms. Available as a variant with Bluetooth or with fixed cable
    • High-precision temperature/humidity probe (0636 9771 or 0636 9772) with an accuracy of ±(0.6% RH + 0.7 % of m.v.) in the range 0 to 90% RH for measuring the humidity in cleanrooms

    Delivery Scope

    testo 440 air velocity and IAQ measuring instrument, 3 x AA batteries, USB cable and calibration protocol.


    Technical data

    Temperature - NTC

    Measuring range
    -40 to +150 °C
    Accuracy
    ±0.4 °C (-40 to -25.1 °C)
    ±0.4 °C (+75 to +99.9 °C)
    ±0.5 % of mv (Remaining Range)
    ±0.3 °C (-25 to +74.9 °C)
    Resolution
    0.1 °C

    Temperature - TC Type K (NiCr-Ni)

    Measuring range
    -200 to +1370 °C
    Accuracy
    ±(0.3 °C + 0.3 % of mv)
    Resolution
    0.1 °C

    General technical data

    Weight
    250 g
    Dimensions
    154 x 65 x 32 mm
    Operating temperature
    -20 to +50 °C
    Connectable probes
    1 x digital probe with cable or 1 x Temperature NTC TUC, 1 x digital Bluetooth probe or testo Smart Probe, 1 x Temperature TC Type K
    Product colour
    black/orange
    Battery type
    3 AA mignon 1.5 V
    Battery life
    12 h (typically vane measurement)
    Interface
    Bluetooth®; USB
    Storage temperature
    -20 to +50 °C

    Sensor

    Comfort probes

    Humidity probes

    Pressure probes

    Temperature probes

    Velocity

    Applications

    Convenience and maximum flexibility for duct and outlet measurements

    With our large range of air velocity probes (please order separately), you can carry out simple and convenient measurements even at locations that are difficult to access in ventilation ducts or at air outlets:
    you will even find it easy to carry out measurements in particularly large ducts. This is because the extendable telescope on the hot wire and vane probe (Ø 16 mm) with universal handle can be further extended using the telescope extension – enabling you to attain a total length of 2 metres.
    Carry out measurements at air/ceiling outlets effortlessly and without using a ladder. Fit your vane probe (Ø 100 mm) with the telescope with 90° angle and, if necessary, with the telescope extension (both can be ordered separately).
    Greater freedom thanks to Bluetooth: the air velocity probes with Bluetooth have no inconvenient cable connection to the measuring instrument, and they transmit readings up to a distance of 20 m. Press the button on the probe to operate the measuring instrument – for example, to start and stop a series of measurements (timed mean calculation).
    Attach the testo 440 air velocity and IAQ measuring instrument to metal surfaces (e.g. ducts) easily using the practical magnets.
    Benefit from fast calculation of the volume flow: in the “volume flow” measurement menu of the multifunction measuring instrument, configure the dimensions and geometry of the duct cross-section – the measuring instrument shows you the volume flow straight away.
    Volumetric flow measurement in ventilation ducts with vane probe (Ø 16 mm) and testo 440

    Long-term monitoring of indoor air quality

    Poor indoor air quality due to excessive concentrations of CO2 can cause tiredness, lack of concentration and even illness. With its menu for recording readings, the testo 440 air velocity and IAQ measuring instrument is ideal for monitoring the indoor air quality. Enter the measurement time and the measuring cycle – and, for example, track the change in CO2 concentration or humidity and temperature values over the course of the day. Simply choose between probes with Bluetooth or fixed cable for CO2, CO or humidity (please order probes separately).
    Measure CO2 concentration for assessing indoor air quality with CO2 probe and testo 440

    Turbulence measurement in accordance with EN ISO 7730 / ASHRAE 55

    Determine the degree of turbulence and the draught risk in the workplace: draught restricts the comfort level and is the most common cause of complaints about the indoor climate. The turbulence probe (please order separately) measures air velocity and air temperature, and automatically calculates the draught risk and the degree of turbulence in accordance with EN ISO 7730/ASHRAE 55.
    For convenient measurements at varying heights, we recommend using our measuring tripod for comfort level measurement (please order separately). This makes it very easy to position turbulence probes in compliance with the standards.
    Determining the degree of turbulence with turbulence probe and testo 440

    Range of probes for cleanrooms and laboratories

    The testo 440 air velocity & IAQ measuring instrument is also ideal for a wide variety of applications in cleanrooms and laboratories in conjunction with the following probes:
    • High-precision flow measurement in fume cupboards with the fume cupboard probe
    • Thanks to the low start-up speed of 0.1 m/s, the high-precision vane probe (Ø 100 mm) is ideal for laminar flow measurements in cleanrooms. It is available as a variant with Bluetooth or with fixed cable
    • To measure the humidity in cleanrooms, we recommend the high-precision humidity/temperature probe (0636 9771 or 0636 9772). With an accuracy of ±(0.6 %RH + 0.7% of m.v.) (0 to 90 %RH), it also meets the requirements for humidity measurements in this particularly sensitive area
    • Use the high-precision digital Pt100 temperature probes, for example, for high-precision comparative measurements in calibration laboratories, temperature measurements in chemical laboratories or in the cosmetics industry as well as for determining the temperature distribution in refrigerators and conditioning cabinets
    Volumetric flow measurement in fume cupboards with fume cupboard probe and testo 440
